Name: Snap Push-In Rivet, Beveled, Releasable, Knob, PA6 UL94V2, PA66 UL94V0
PA66-polyamide, insulation, environmental protection, acid and alkali resistance,
operating temperature: 80-120°c flame retardant grade: UL94V-2/UL94V-0
1. Material: Fire-proof level PA66（Nylon66) UL94-V2，PA66(Nylon66) UL94-V0
2. Color Available: White、Black、Natural
3. ROHS Compliant Certification
Remark: All products which are manufactured in UL94 -V2 Nylon 66,
or UL94 -V0 Nylon 66, are black colors as standard. unless otherwise
noted. These materials can be colored to match your requirements.
Our fasteners and fixings cover a wide selection of plastic mountings and offer various application options for fixed connections, suitable for manufacturing needs in the automotive or electrical industry. A clever solution for components based on a process in assembly and production.
Product Specification
Mounting Buttons Removable, Snap Push-In Rivet, Beveled, Releasable, Knob, PA6 UL94V2, PA66 UL94V0.
JX-RH Type Snap Rivets
Our range of PA6 nylon snap rivets (JX-RH) is a pre-assembled two-piece push-in rivet. Just place the rivet into the hole and push it down. With a clean, neat finish, these plastic push rivets represent the fastest, easiest method of fastening two panels together.Easy to use countersunk nylon rivet
Pre-assembled Pop in the hole and push down Clean & neat finish
Nylon66 UL94-V2
Temperature Range: -30 to +85°C
Color: Black
Other Colours to specification to order Available in Flame Retardant (V0) to order.
Remark: RoHS-compliant
Our range of nylon snap rivets is pre-assembled, pushed into the hole, and pressed down for a clean, neat finish. An easy method to fasten two panels together. Available as a permanent panel fastener in the push rivet. The JX-RH-Type and JX-T-Type snap rivets are easily removed if required. These rivets are RoHS Compliant and also available in Flame Retardant (V0) nylon
Snap Rivets are a two-piece assembled product featuring a body and pin or mandrel. The body pushes into the panel, and the pin pushes down into the body. This forces the body to open and securely hold in place within the panel. This is typically a non-removable item.
JX-RH-Type & JX-RT-Type Snap Rivets—These are two-piece pre-assembled rivets featuring a body and pin. They are inserted into a hole in the panel and pushed home. Unlike the standard snap rivet, these can also be removed by pulling on the oversized head and then reused.
