Nylon Sheet Edge Insert JX-GSEI

Sheet Edge Inserts In stock Manufacturing

Sheet Edge Inserts provide strong threads for metal sheets that are too thin to be tapped. They are fastened to the edges of thin sheets and are a good alternative to self-clinching inserts.

To Install;

1. Install insert notch into the side of the panel opening

2. Rotate the spring leg of the insert toward the panel. This compresses the spring leg, allowing it to pass through the notch in the panel

3. The leg will snap back to its normal position, securing the insert into the panel.

Please Note: The internal thread requires a screwdriver for installation.

The insert can be removed after installation by simply pinching the spring legs together and rotating.

Material: Polyamide 6/6

Color: Black

UL94 V2 flame rated.

Packaging Standard

At Juxin Fasteners, we apply standardized export packaging to ensure product protection, traceability, and compliance with international logistics requirements.

1. Standard Export Packaging

Unless otherwise specified, all products will be packed according to our factory standard export packaging, which includes:

Moisture-resistant inner protection

Poly bag or small box packing as required

Reinforced export cartons

Clear labeling with part number, specification, batch number, and quantity

Palletizing for sea or air shipment when necessary

Our standard packaging is designed to ensure safe transportation, efficient warehousing, and long-distance international shipping.

2. Customized Packaging Options

We also provide customized packaging solutions according to customer requirements, including but not limited to:

Private labeling

Customized barcodes

Specific carton dimensions

Retail packaging

Special pallet configuration

Customer-specific marking and identification

So that you know, customized packaging may involve additional costs and extended lead time depending on the complexity of the requirements.

3. Compliance & Quality Assurance

All packaging processes are controlled under our ISO 9001 quality management system to ensure consistency, traceability, and product integrity throughout the supply chain.
