Name: JX-LTBS Dual Locking Circuit Board Support
Material: P.C. board isolation column JX-LTBS type. Qualified NYLON66 (natural color), fire rating 94V-2, not easy to age, high degree of insulation.
Usage: It is tool-free and easy to load and unload by hand. Drill 4.0mm, 4.8-5.0mm holes in the substrate, fix the isolation column, and then put the P.C. board into it.
Characteristics: Double-lock type, strong fixing force, insertion, not easy to come off the set.
Usage: For fixing the P.C.B. board.
P.C.B. Support - Spacer - Locking/Non Locking Two Prong, Spacers for snap or self-adhesive mounting. These spacers have different locking and removal designs on the head of the spacer.
Furthermore, we offer different hole diameters, lengths, and plate thicknesses.
Product Specification
Dual Locking Snap-In Supports, PCB Support - Spacer - with Locking Arrowhead Both ends snap and lock in place for a permanent connection. Made of nylon, these supports have excellent wear and abrasion resistance and resist chemicals and solvents (except mineral acids). Exposure to moisture may cause them to expand.
All meet UL 94 flammability standards. Supports that meet UL 94 V-0 stop burning within 30 seconds if they catch fire, and supports that meet UL 94 V-2 stop burning within 10 seconds if they catch fire.
Juxin Fastening Solutions is constantly expanding the selection of new products and innovations. With our vast product range, we offer efficient solutions for many projects.
More about the latest updates on our products can be found here. Always one step ahead.
