Name: Nylon Push Spacer
Material: UL-approved NYLON66 (natural color), fire rating 94V-2,
sound insulation, not easy to age.
1. Hole: 4.75±0.08mm
Panel Thickness: 0.79-1.98mm
2. Hole: 3.18±0.05mm
Panel Thickness: 0.79-1.98mm
PCB Support - Spacer, Locking Arrowhead, Teardrop, Locking Bayonet, Flat Rest, Round, Hexagonal
These special spacers support many applications, especially when conventional fastening solutions reach their limits.
These metric push-in spacers are designed to support heavily loaded circuit boards. No through hole is required on the board, allowing easy access to the underside. They have a flanged base to keep them steady.
Product Specification
These metric push-in spacers are designed to support heavily loaded circuit boards. No through hole is required in the board, allowing easy access to the underside. They have a flanged base to keep them steady.
Our range of Push Spacers is available in different lengths from 3.20mm to 22.20mm; they are suitable for use with a hole diameter of 3.18mm or 4.75mm and a panel thickness of 0.79-1.98mm. They are easy to install with a push fitting and securely grip the PCB
Product Pictures
