Name: Flat-Top Snap-In Supports
Material:PA66(natural color).
Fire rating:94V-2, sound insulation, not easy to age.
Usage: First, drill 5.5mm holes in the substrate, push the isolation column from the bottom to fix it, and then fix the PC board.
Features: No tools are needed to fix the PC board, and it is easy to disassemble when replacing or repairing it.
The flat top supports boards without drilling a hole, while wings on the other end add tension for a secure hold in a hole. Made of nylon, these supports have excellent wear and abrasion resistance and resist chemicals and solvents (except mineral acids). Exposure to moisture may cause them to expand.
Product Specification
SIZE AND SHAPE: The size and shape of isolation posts may vary depending on the manufacturer and the specific application. They can be cylindrical, square, or other shapes, and the size will vary depending on the need.
Temperature Resistance: Since electronic equipment may operate in high-temperature environments, PC board isolation posts typically have good temperature resistance to ensure stable operation under various operating conditions.
Mounting: Isolation posts can be mounted on circuit boards using plug-in or surface-mount methods, depending on design requirements and manufacturing processes.
Electrical Characteristics: Isolation posts are designed with electrical characteristics in mind to ensure the isolation of practical circuits and prevent electrical signals from interfering or crossing.
APPLICATIONS: PC board isolation posts are widely used in power supply modules, communication equipment, computer hardware, and other electronic devices to isolate and separate circuits.
Product Pictures
