Name: Rotary Speed Limiters
Material:POM UL94HB, PC UL94V2
Install these rotary speed limiters at the hinges of small lids, doors, and access panels for smooth, quiet motion. They're often used in electronics applications.
Speed limiters with a 360° rotation angle are often used to move small hoods, flaps, and fans. A cycle is one shaft rotation.
Dual-direction speed limiters dampen motion in both directions. Common uses for them include controlling the motion of a switch-activated door and opening and closing a DVD player.
Clockwise and counterclockwise speed limiters dampen motion in the listed direction while moving freely in the opposite direction. They are used in processes that require returning a part to its original position.
Speed limiters with a geared shaft must be used with gears having the same 20° pressure angle as the module.
Product Specification
1. It has good abrasion resistance, a high relative sliding speed, and a long working life, which allows it to be used in the transmission parts of many machines.
2. It has a high load-carrying capacity. Due to its smooth surface and rubber-like flexibility eliminates noise and vibration and is suitable for use in situations requiring high loads.
3. Wide operating temperature range from -40℃ to +80℃, suitable for mechanical equipment in different environments.
4. Good workability, self-lubrication, and a low coefficient of friction can reduce power consumption and save power consumption costs.
5. Under certain conditions, even if the deformation is also very cracks lead to damage, the root of the teeth to strengthen the treatment to improve the bending fatigue strength further.
6. Good dimensional stability will not appear when oil seepage occurs.
7. It is tough and durable, has low-speed noise, and is highly corrosion-resistant, allowing it to adapt to a variety of acid, alkali, and salt media.
Product Pictures
