Turn Panel Fastener JX-G84103-90-010

Quarter Turn Fasteners: In Stock, Manufacturing.

Quarter Turn Panel Fasteners, commonly known as Quarter-turn Studs or Rivets, engage receptacles and are fastened by turning the stud approximately 90 degrees—a process known as a 'quarter-turn rotation'. The fastener provides a predictable holding force and offers a detent in the locked position that resists opening in error. Quarter-turn fasteners and assembly parts offer a solution that is quick yet secure in its assembly. Plastic Quarter Turn Rivets are a fastener that provides a permanent mounting solution—an ideal choice for security panels and components that require rapid replacement.

To install and remove Plastic Quarter Turn Fasteners: Use a flat-head screwdriver or a coin and give the fastener a quarter-turn. This releases the bottom panel while retaining the fastener in the removable panel. Alternatively, drive the plunger into the grommet with a hammer that locks two panels together.

Our Quarter Turn Fastener range is available in a choice of materials, including Acetal Co-Polymer, Acetal RMS-14, Polyoxymethylene (POM), Nylon 6/6, and Polyamide.

Crossed and Slotted Drive Types

Suitable for a wide range of panel depths and mounting hole sizes

Quick-release and fast assembly

Locks and unlocks with an easy quarter-turn rotation

Materials: Acetal, Acetal Co-polymer, POM, Nylon, and PA

UL94 HB and UL94 V2 flame rated options available

Colours: Black, Natural, and White
