Key Slot with Locking Bayonet Nose JX-MS-6

Name: Key Slot Locking Support Post

PCB Support - Spacer - Locking Bajonet with locking Two Prong and Keyslot, Keyhole

Material: PC board Key Slot Locking Support Post JX-MS type. Qualified NYLON66 (natural color), fire rating 94V-2, not easy to age, high insulation.

Usage: First, drill 4.5mm holes in the base plate, then insert the isolation column into the base plate hole.

Usage: Support the PC board and increase its stability of PC board.

Spacers for snap or self-adhesive mounting. These spacers have different locking and removal designs on the head of the spacer.

Furthermore, we offer different hole diameters, lengths, and plate thicknesses.

The flat top supports boards without drilling a hole, while wings on the other end add tension for a secure hold in a hole. Made of nylon, these supports are excellent in terms of wear and abrasion resistance and resist chemicals and solvents (except mineral acids). Exposure to moisture may cause them to expand.
