Name: Locking Circuit Board Support JX-GLSP8
Material: PA66 UL94V2 (GMS-01); PA66 UL94V0 (GMS-02)
Top Hole: 4.75±0.08mm
Panel Thickness: 0.2-1.4mm
Bottom Hole: 4.0±0.08mm
Panel Thickness: 1.57mm
Dual locking circuit board support is supplied in UL94 V2 nylon 6/6 RMS-01 or UL94 V0 RMS-19. It features a snap-in-fit feature that makes it easier to fit into the PCB. It provides good strength to the board and chassis and prevents rotation.
Applications and Benefits of Dual Locking Circuit Board Support
Supplied in UL94 V2 nylon 6/6 RMS-01 or UL94 V0 RMS-19.
It features a snap-in fit for easy fitting.
Provides good strength to the PCB.Prevents rotation.
Product Specification
Locking Circuit Board Support JX-GLSP8
PCB supports, which have various names, including PCB support pillars and PCB support posts, are essentially designed to support the mounting and joining of a PCB (printed circuit board) onto a chassis or surface.PCB supports are also renowned for their insulation and protection properties and for providing a secure and stable hold.
We offer PCB supports in various mounting types, including double-sided mounting and non-threaded options manufactured from plastic and nylon. We also offer spacers for snap or self-adhesive mounting. The head of these spacers has different locking and removal designs.
Furthermore, we offer different hole diameters, lengths, and plate thicknesses.
Product Pictures
