Name: Reverse Locking Spacer&Reverse Lock Circuit
Board Support
Flat bottom isolation column JX-1104-RS
Material: Flat bottom isolation post JX-1104-RS type. Qualified NYLON66 (natural color), fire rating 94V-2, sound insulation, not easy to age.
Usage: First, drill 5.5mmφ holes in the substrate, then push the isolation column upward from the bottom to fix it, and then fix the PC board.
Features: PC board can be fixed without tools; easy to disassemble when replacing or repairing PC board.
This is a push-reverse locking spacer with a flat top mounted on the underside of the board. It is designed to fit through the bottom of a PCB and connect to the panel above.
Our wide range of PCB accessories offers an extensive selection of PCB Spacers, pillars, supports, and standoffs to support, lock, space, or guide the PCB board.
Discover accessories for appliances (white goods), electrical cabinets, machinery, or other equipment with PCB support.
Product Specification
Cupped Reverse Locking Circuit Board Support.
PCB Support - Spacer - Locking/Non Locking Bayonet, Locking Arrowhead, Locking Two Prong, Reverse Locking Support, Push Spacer
Material: flat bottom isolation post RS type. Qualified NYLON66 (natural color), fire rating 94V-2, sound insulation, not easy to age.
Usage: First, drill 3.5,5.0,6.1,6.6mmφ holes in the substrate, push the isolation column upward from the bottom to fix it, and then fix the PC board.
Features: PC board can be fixed without tools; easy to disassemble when replacing or repairing PC board.
Temperature Resistance: Since electronic devices may operate in high-temperature environments, PC board isolation posts usually have good temperature resistance to ensure stable operation under various working conditions.
Mounting: Isolation posts can be mounted on the board using plug-in or surface-mount methods, depending on the design requirements and manufacturing process.
Electrical Characteristics: Isolation posts are designed with electrical characteristics in mind to ensure the isolation of practical circuits and prevent electrical signals from interfering or crossing.
APPLICATIONS: PC board isolation posts are widely used in power supply modules, communication equipment, computer hardware, and other electronic devices to isolate and separate circuits.
