Name:White Nylon Snap Rivets, R-type rivets
Material: Nylon66,PA66-polyamide, insulation, environmental
1. Material: Fire-proof level PA66（Nylon66) UL94-V2，PA66(Nylon66) UL94-V0
2. Color Available: White、Black、Natural
3. ROHS Compliant Certification, Temperature: 80-120°c
The most important physical performance indicators:
1. The degree of fit between the main rivet diameter and the opening diameter.
2. Nominal pull-out force.
The most important chemical performance indicators:
1. Acid resistance.
2. Alkali resistance.
3. Fire rating.
4. Insulation performance
Relative to ordinary metal rivets, nylon rivets have chemical properties, physical properties, and special characteristics. In insulation, corrosion resistance, acid and alkali, and so on, better than conventional rivets. And its own quality is relatively light. Relative to the screws, nylon rivets in the assembly speed is more convenient, without any tools to complete the assembly. Of course, its shortcomings are also obvious, pulling force is generally inferior to ordinary rivets and screws.
Snap Rivets, also known as Push Snaps, are a quick, easy fastener solution that can be installed without tools!
Browse our Nylon Snap Rivets available in Nylon 6, Nylon 6/6, Nylon 6/66, and Nylon 4/6. The Push-in Rivets are manufactured to UL94 V0 or UL94 V2. These snaps and rivets are fast and economical. The two-piece molded fastener comes assembled and ready to use. They feature specially designed legs that expand and firmly lock the components permanently in place. Heat-resistant options can withstand temperatures of up to 266F (130 °C).
Also available are p-type snap rivets intended for high-temperature applications. Made from black Polysulfide (PSU) and rated UL94 HB, these push-in rivets can withstand temperatures up to 311F (155 °C).
Good thermal and electrical insulation properties
Colors: Black, White, and Tan
No tools needed.
Product Specification
A nylon rivet is a kind of mechanical fastener for connecting PC board or other materials, applicable to the following scope:
1. For automotive plastic battery covers, aviation, ships, trains, construction, and other industrial manufacturing, the PC board connection is fixed;
2. Used for PC board and other materials fixed connection in electrical appliances, instruments, electronic equipment, furniture, and other industries;
3. Used for the connection between PC boards, ceilings, partition boards, and other panels in the industries of electric power, telecommunication equipment, machine room decoration, and so on;
4. Used for the connection of threads, pipes, valve bodies, and other components in the industries of machine manufacturing, maintenance, and so on;
Five 、Used for outdoor activities, camping, and other occasions such as tents, awnings, canvas canopies, and other materials connection.
Product Pictures
