Telecommunications equipment increasingly combines metal cabinets, polymer housings, plastic covers, brackets, cable management components, and internal electronic assemblies.
These components often require compact and reliable fastening points without adding unnecessary hardware to the enclosure design.
Product Specification
Telecom equipment combines metal cabinets, plastic housings, molded brackets, electronic modules, cable-management components, and other precision parts. As equipment becomes more compact and increasingly modular, reliable fastening points inside plastic components become increasingly important.
Telecom threaded inserts provide a durable metal thread inside plastic or composite components, helping manufacturers create reliable fastening points where directly molded plastic threads may not provide the required assembly performance.
For telecom equipment manufacturers, selecting the right insert involves more than choosing a thread size. Plastic material, boss geometry, installation method, assembly torque, corrosion environment, dimensional requirements, and production volume all need to be considered together.
JUXIN Fasteners provides OEM custom threaded inserts according to customer drawings, material requirements, thread specifications, installation processes, surface treatment requirements, and application conditions.
Telecom cabinets and communication equipment frequently use plastic housings and internal molded components to reduce weight, provide electrical insulation, simplify manufacturing, and achieve complex product geometries.
However, plastic threads can be affected by repeated screw installation, assembly torque, material deformation, and long-term mechanical loading.
Threaded inserts for telecom cabinets provide a dedicated metal thread within the plastic component. This can be particularly useful where screws need to be installed, removed, or serviced repeatedly.
Typical applications include:
Telecom equipment housings and plastic enclosures
5G and wireless communication equipment
Network equipment and communication modules
Outdoor telecom cabinets
Plastic mounting brackets and support structures
PCB and electronic module mounting points
Cable management components
Cooling and thermal-management assemblies
RF and communication equipment modules
Electronic control and communication systems
Plastic threads can be vulnerable to stripping, deformation, or wear when assembly torque is high or when components require repeated servicing.
A metal threaded insert provides a dedicated internal thread and can help improve the durability and repeatability of the fastening point.
Telecom equipment may require maintenance, component replacement, or field servicing during its service life.
Properly selected threaded inserts can support repeated screw installation and removal while reducing reliance on the plastic material itself to carry the complete thread load.
Threaded inserts can create a compact fastening point inside a plastic housing without requiring a conventional nut on the rear side.
This is particularly useful when internal space is limited or when the opposite side of the component is inaccessible after assembly.
Threaded inserts for plastic housings should be selected according to the plastic material, boss geometry, installation process, thread specification, and expected assembly requirements.
The insert therefore becomes part of the overall component design rather than simply being treated as a standard hardware item.
Technical challenge: Plastic housings may experience thread wear or deformation when screws are repeatedly installed and removed.
JUXIN OEM solution: Metal threaded inserts provide a dedicated internal thread that can be matched to the required screw size and assembly conditions.
The insert geometry and installation method can also be considered together with the plastic boss design to support the required retention performance.
Technical challenge: Outdoor telecom cabinets and communication equipment can be exposed to humidity, condensation, salt spray, and other corrosive environmental conditions.
JUXIN OEM solution: JUXIN can provide customized plating and surface treatment solutions according to the customer's specified corrosion-resistance requirements.
When a customer requires higher corrosion resistance, salt spray performance of up to 1,200 hours can be achieved through an appropriate plating or surface treatment solution,
depending on the substrate, coating system, and specified testing requirements.
The coating specification should therefore be selected according to the actual application and customer requirement rather than assuming that one surface treatment is suitable for every telecom application.
Technical challenge: High-volume telecom production requires fastening components with consistent dimensions and repeatable installation performance.
JUXIN OEM solution: Insert dimensions, thread specifications, external geometry, and other critical characteristics can be controlled according to customer drawings and production requirements.
For automated assembly, the insert design can also be considered in relation to feeding, positioning, and installation requirements.
Technical challenge: Electronic and telecom housings often contain multiple components in a limited internal space.
JUXIN OEM solution: Threaded inserts can be customized in terms of thread size, length, outside diameter, external profile, and installation configuration to fit the available component geometry.
Brass threaded inserts for electronics are widely used for electronic housings, plastic enclosures, control modules, and communication equipment.
Brass provides a practical combination of machinability, electrical conductivity, and compatibility with many engineering plastics.
For plastic telecom housings and electronic modules, brass is a commonly considered material when a durable metal thread is required inside the molded component.
Stainless steel inserts for outdoor enclosures can be considered for applications where higher corrosion resistance or specific mechanical and environmental requirements are important.
They may be suitable for demanding outdoor telecom equipment where the fastening component must withstand a more aggressive operating environment.
Material selection should take into account the surrounding environment, mating materials, mechanical requirements, and surface-treatment requirements.
Aluminum inserts can be considered where low weight is an important design requirement.
Material selection should be evaluated together with thread strength, corrosion conditions, mating materials, installation requirements, and the required surface treatment.
Heat staking threaded inserts are commonly used with thermoplastic components.
During installation, the insert is heated and positioned into a molded boss. The surrounding thermoplastic material softens and forms around the external geometry of the insert.
This method can provide a secure fastening point and can be suitable for high-volume plastic component production.
Ultrasonic installation uses controlled ultrasonic energy to soften the surrounding thermoplastic material and embed the insert into the component.
This method can be suitable for automated production where repeatable installation and cycle efficiency are important.
The insert geometry and plastic material should be evaluated together to achieve the required installation and retention performance.
Press-fit inserts are mechanically installed into a prepared hole.
The external geometry of the insert, hole dimensions, plastic material, and installation force should be considered carefully to obtain the required retention performance without creating excessive stress in the component.
For some high-volume applications, inserts can be positioned during the molding process so that the plastic component is formed around the insert.
This approach can integrate the fastening point directly into the molded component and should be considered during the initial product-design stage.
Telecom equipment manufacturers frequently require fastening components that fit a specific enclosure, bracket, module, or assembly process.
A standard catalog insert may not always match the required geometry, installation process, material, or environmental requirements.
JUXIN provides OEM custom threaded inserts according to customer drawings and technical requirements, including:
Custom thread dimensions
Custom insert length
Custom outside diameter
Knurled or specially profiled external surfaces
Special installation features
Material selection
Plating and surface treatment
Packaging and production requirements
For new projects, customers can provide drawings, 3D models, samples, thread specifications, plastic material information, installation requirements, or application conditions.
JUXIN can then evaluate the appropriate insert configuration and manufacturing process according to the project requirements.
Choosing the correct threaded insert requires more than selecting the thread size.
The insert and plastic component should be evaluated as one fastening system.
Important design factors include:
Plastic type and mechanical properties
Glass-fiber or other reinforcement in the plastic
Boss diameter and wall thickness
Insert outside diameter and length
Thread size and thread engagement
Installation method
Assembly torque
Pull-out and torque-out requirements
Operating temperature
Humidity and corrosion environment
Required surface treatment
Production volume and installation automation
For reinforced engineering plastics, the insert geometry and installation process should be evaluated carefully because the plastic's stiffness, shrinkage behavior, and boss geometry can influence insert retention and local stress.
Telecom manufacturers typically require stable quality across repeated production batches.
Small dimensional differences in threaded inserts can affect automated installation, screw engagement, component fit, and final assembly performance.
For this reason, important characteristics such as thread dimensions, outside diameter, length, external geometry, and surface treatment should be controlled according to the applicable drawing and production specification.
For high-volume projects, production planning can also consider automated feeding, inspection requirements, packaging configuration, batch control, and delivery schedules.
A reliable telecom fastening solution should be considered early in the product-development process.
During prototype development, engineers can evaluate the insert geometry, installation method, plastic boss design, assembly torque, and retention requirements.
Once the design is approved, the same technical requirements can be transferred into mass production with appropriate process controls and inspection requirements.
Early evaluation can help reduce the risk of selecting an insert that works during prototyping but creates assembly or reliability problems during volume production.
Although telecom threaded inserts are particularly relevant to communication equipment, similar fastening requirements exist across many industries:
Telecommunications and 5G infrastructure
Network and data communication equipment
Electronic equipment
Industrial control systems
Automotive electronics
EV electrical systems
Medical equipment
HVAC equipment
Industrial automation
Robotics
Energy and power equipment
Outdoor electrical enclosures
JUXIN Fasteners focuses on industrial fastening solutions for OEM and engineering applications.
Our manufacturing capabilities cover a range of custom fastener requirements, allowing threaded inserts to be developed around the customer's actual component and assembly requirements.
Instead of selecting a threaded insert only by thread size, JUXIN considers the complete application,
including plastic material, boss geometry, installation method, assembly requirements, operating environment, corrosion resistance, and production volume.
This engineering-oriented approach helps customers develop a fastening solution that is practical for both product performance and manufacturing.
If you are developing a telecom cabinet, communication enclosure, plastic housing, network equipment module, or other electronic assembly that requires a reliable metal threaded fastening point,
JUXIN can support your project with OEM custom threaded inserts and application-specific fastening solutions.
Send us your drawing, sample, thread specification, plastic material, installation method, surface-treatment requirement, or application conditions.
